Features
- The 3000 Intimidator is a 4-flute, high performance end mill designed for difficult to machine ferrous materials
- The 3000 Intimidator can be used in full slotting, roughing, and finishing applications and its specially designed flute relief and unequally spaced index provides chatter-free machining
- The 3000 Intimidator is stocked with FC-18 coating
Product Specifications
| Cutting Diameter (Decimal Inch) | 0.5000″ |
| Cutting Diameter (mm) | 12.70mm |
| Cutting Diameter (Inch) | 1/2″ |
| Cutting Flute Length (Decimal Inch) | 1″ |
| Cutting Flute Length (mm) | 25.40mm |
| Cutting Flute Length (Inch) | 1″ |
| Shank Diameter (Decimal Inch) | 0.5000″ |
| Shank Diameter (mm) | 12.70mm |
| Shank Diameter (Inch) | 1/2″ |
| Overall Length (Decimal Inch) | 3.0000″ |
| Overall Length (mm) | 76.20mm |
| Overall Length (Inch) | 3″ |
| Coating/Finish | FC18 |
| Metric/Inch | Inch |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 38 |
| Flute Spiral Direction | Right Hand |
| Direction of Cut | Right Hand |
| Point End Type | Corner Radius |
| End Type Character Designation | R |
| Radius (Decimal Inch) | 0.1250″ |
| Radius (mm) | 3.18mm |
| End Type | Single End |
| Coolant Through | Non Coolant Through |
| Weldon Flat | Yes |
| Length | Standard |
| Length Designator | SD |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
